PEAK-System with innovations at embedded world 2019
Febrauary 14, 2019
PEAK-System, a company specializing in classical CAN and modern CAN FD, will present its latest products at embedded world 2019. "Like every year before, we as a German manufacturer and provider are proud to be able to prove our long-standing know-how again", so the managing director Uwe Wilhelm.
Exhibition visitors can take a look at the PCAN-MiniDiag FD, which was released at the end of January 2019, and the new PCAN-MicroMod FD product series, which will be released after the exhibition. The plug-in module PCAN-MicroMod FD, the development board PCAN-MicroMod FD Evaluation Board, and the PCAN-MicroMod FD motherboards Analog 1, Digital 1, and Digital 2 will be available. In addition, the first product of a CANopen series will be shown, which will be launched in the second half of the year.
Access to CAN FD buses via the LAN interface of a computer is to be made possible by the PCAN-Gateway FD DR at the end of 2019. A first prototype of this Linux-based module in a DIN rail housing will also be shown.
Last but not least, exhibition visitors can take a closer look at the PCAN-Router Pro FD announced for the third quarter, which is equipped with six CAN FD channels, I/Os, and data logger and can be configured with Windows software.
PEAK-System can be found at embedded world 2019 in hall 1, booth 483. The exhibition will take place from February 26th to 28th in Nuremberg, Germany. It is an important annual event for professionals from all over the world to find out about the latest embedded technologies for hardware, software, and tools.
Website of the exhibition: www.embedded-world.de
The German company PEAK-System has published the handheld device PCAN-MiniDiag FD for the basic diagnosis and fast checking of CAN and CAN FD buses
The German company PEAK-System has published the handheld device PCAN-MiniDiag FD for the basic diagnosis and fast checking of CAN and CAN FD buses. The battery-powered device has functions which show, for example, the termination, bus load, message and error counters as well as the levels at the CAN connection. In particular, for the first time, users can access any CAN network in a matter of seconds with the innovative transmission rate detection. More precisely, bit timing measurements are used to determine the nominal bit rate for CAN and the data bit rate for CAN FD.
The PCAN-MiniDiag FD can easily be operated with one hand due to its compact size and fits into any conventional trouser or jacket pocket. The device is suitable for service technicians and developers who want to quickly access unknown CAN networks in vehicles, machines, or industrial facilities and perform simple diagnostics. The PCAN-MiniDiag FD has a D-Sub connector, an OLED display, a membrane keyboard with four keys, and a housing with increased IP42 ingress protection.
Aukua delivers 3-in-1 Automotive Ethernet testing solution!
Aukua Systems 3-in-1 Automotive Ethernet testing solution delivers three powerful tools in one platform!
Network Impairment Emulation: see how delay, impairments and bandwidth affect automotive systems, applications and security
Inline Packet Capture and Protocol Analyzer: capture packets, monitor traffic in real-time, and troubleshoot hard to find problems
Traffic Generator: verify system integrity, throughput performance and measure system latency
Aukua is working to help Automotive semiconductor companies, Tier 1 suppliers and OEM Manufacturers leverage Automotive Ethernet so they can rapidly innovate with confidence and deliver new in-vehicle services and infortainment features, while improving safety with new advanced driver assistance systems (ADAS).
Peak-System Technik GmbH
PEAK-SYSTEM is expanding their CAN FD product line and releasing the brand new PCAN-M.2 Four Channel card for M.2 interfaces. Thanks to the mounted expansion board on the main board, four CAN FD channels are available for computers. Each CAN FD channel can transmit a maximum of 64 data bytes of a CAN FD frame at bit rates of 20 kbit/s up to 12 Mbit/s. Each channel is also galvanically isolated up to 300 volts and can be terminated.
The card can be used on any motherboard size from Mini-ITX to E-ATX. Thus, the plug-in card is suitable for desktop and industrial PC cases of various sizes. Especially for embedded systems, such as those found in motor vehicles, railways, and aircraft, the CAN FD interface is ideal due to its size and compactness.
Device drivers are available for the operating systems Windows (10, 8.1 and 7) and Linux.
For further information, just follow this link: https://lnkd.in/d3wEfrT
USB adapter for LIN with master/slave functionality
May 31, 2018
PEAK-System launched a compact USB adapter called PLIN-USB for connecting a computer to a LIN network. The LIN adapter is intended for service technicians for diagnosis of LIN buses and for developers of vehicle networks. The adapter supports the LIN protocol according to ISO 17987 and meets all LIN specifications up to version 2.2. The LIN interface can be used in master or slave mode.
For more details write to pcantool@embeddedindia.com
Aukua's MGA2510 is the first and only traffic generator to support Energy Efficient Ethernet (EEE) or IEEE 802.3az operation!
March 16, 2018 - June 30, 2018
It is now possible to validate EEE operations, characterize latency and throughput performance and inject impairments for negative and functional testing all directly over a EEE enabled link.
This new feature is supported for 1000BASE-T, 2.5GBASE-T, 5GBASE-T and 10GBASE-T.
Please contact aukuasales@esaindia.com or call +91-9886080011 to schedule a demo today!
Uwe Wilhelm, CEO of Peak-System at Embedded World 2018 - PEAK-System PCAN-PCI/104-Express FD Four Channel
May, 2018
March 16, 2018 - June 30, 2018
For Registration Visit: www.hackster.io/contests/wiznet
“Serial to Ethernet, StablE" is an international
project contest for developers worldwide, powered by WIZnet.
This contest gives developers an opportunity to showcase
their skills in IoT innovation and competency.
We invite all contestants to explore WIZnet's new serial to
Ethernet device, WIZ750SR. Any idea or project submission based
on WIZ750SR will be accepted, because every project will enhance
the functions of WIZ750SR and empower its usefulness.
For contestants, WIZnet provides the standard firmware which
supports configuration of the device by Ethernet and data
exchange between serial and Ethernet under plenty of options.
Contestants had better use the basic software framework and add
only their idea on it. Of course, they can design their own
complete code from the beginning just using WIZ750SR as a HW
platform. It is recommended to use any kind of sensors,
actuators or any other devices additionally to differentiate
your project from others.
Submit your ideas during the first phase of the contest, May 16
~ April 20, for a chance to win a free WIZ750SR board to build
your project and win cash prizes!
For Registration Visit: www.hackster.io/contests/wiznet
For More Information about the contest, write to:
Email: sales@embeddedindia.com
Phone: 080-6764 8888
Website: www.embeddedindia.com; www.esaindia.com
Tesla owners are required to have the Peak-System’s PCAN-USB adapter..
Tesla owners are required to have the PCAN-USB adapter and Tesla’s Event Data Recorder (EDR) Retrieval Program to generate a PDF report outlining the findings from their electric cars’ data recorder.
Tesla is now allowing owners of its vehicles to access their cars’ Event Data Recorder (EDR), commonly known as the ‘black box’ of autos, through a set of licensed tools and software.
As noted by Tesla on its official help page for its EDR user guide, all of the company’s vehicles save for the original Roadster are equipped with an Event Data Recorder. The recording devices are only activated once the vehicle senses a non-trivial physical occurrence in the vehicle. Thus, during normal driving conditions, the EDR is deactivated.
In the event that data logs from the EDR need to be accessed, however, Tesla’s new set of proprietary tools and software can retrieve data from the vehicle’s black box. The following hardware is required to gain access to the data to the Model S, X, and 3’s EDR.
- A Windows computer (Mac OSX and Linux are not supported)
- A PCAN-USB, which is a USB-to-CAN adapter manufactured by Peak System
- The appropriate Tesla Model S, X, or 3 cable from the EDR Retrieval Hardware Kit
INTERNATIONAL EXHIBITION & CONFERENCE ON THE INTERNET OF THINGS
Goplam Embedded Systems, along with partners SolidThinking, an Altair company, are participating in the IoT Asia 2018. SolidThinking products ‘EMBED, ACTIVATE, COMPOSE’ will be showcased and demonstrated.
For more details on the products on display, visit
www.embeddedsingapore.com/products/model-based-system-design/solidthinking
IoT Asia’s aim is to provide a neutral platform for technology influencers to discuss the latest trends and challenges within the industry. For the past 4 years, IoT Asia has been at the forefront of bringing global collaboration and partnership opportunities to governments, businesses and communities in Asia. IoT Asia is an award winning stage that brings together technology heads, design architects, solution architects, engineers, academic institutions, investors and start-ups to assess the latest trends and partnership models in Asia. Featuring a 6,000 sqm exhibition, multi-track thought provoking conferences and community-driven seminars, IoT Asia 2018 will put the spotlight on the following key areas critical to the development of IoT in Asia: Smart Cities, Industrial IoT, IoT Data Analytics, Enablers.
For more information about SolidThinking products contact:
Gopalam Embedded Systems Pte Ltd,
Phone: (65) 6295 1646, HP: (65) 9184 7992 or 9649 7444
Email ID (Sales): sales@embeddedsingapore.com
Email ID (Support): support@embeddedsingapore.com
Webinar on Verifying RTOS Applications using Deep Insight Analysis-Sept 27th
WEBINAR with Jacob Beningo
Time-to-market and reliable products - sounds like contradictive requirements. You can master both by applying the right tools and techniques. Very much dependent on the right concept - selecting the right RTOS and the use of capable tools - keeps you focusing on your application.
GES announces its partnership with Artila. ESS aspires to add force to Artila’s mission to empower device manufactures and system integrators to realize pervasive computing by providing quality products to help our customers incorporate Ethernet connectivity, Web services and embedded computing into their products and solutions, in Singapore, Malaysia and other ASEAN regions.
GES announces its partnership with MicroMax Computer Intelligence. MicroMax is an engineering company, designing specialized computer systems for mission critical applications, with a client base that includes the transportation industry (rail, marine and air), various industrial and manufacturing enterprises as well as financial and federal and municipal agencies. MicroMax systems are excellent for harsh scenarios such as train or marine use, limited-sheltered outdoor applications in heat and cold, and tough industrial environments with dust, dirt, and other contaminants. With this partnership GES hopes to serve customers build rugged customizable industrial systems for tough environment, in Singapore, Malaysia and other ASEAN regions.
