Power Analysis Tools

Quarch offers advanced power analysis tools, particularly the Power Analysis Module (PAM), designed to accurately measure and analyze power consumption in various devices and systems.

Key Features of Quarch Power Analysis Module (PAM)

• Real-World Measurement

  The PAM operates in real-world environments, measuring the power supplied from the host system to the device under test. This allows for accurate assessments of system interactions and power consumption.

• Wide Device Support

  It supports a broader range of devices and can measure multiple power rails, making it versatile for different testing scenarios.

• Programmable Voltage Outputs

  The module allows programming of arbitrary voltage output waveforms, enabling simulations of various power conditions such as power-up ramps and power failures.

• High-Speed Recording

  The PAM features a high-speed record function that captures voltage, current, and power consumption like an oscilloscope, providing detailed insights into device performance.

• Plug-and-Play Fixtures

  The PAM includes plug-and-play interposers and fixtures that facilitate easy setup and integration with various devices, enhancing usability.

Applications

• Power Consumption Monitoring

  The PAM is ideal for monitoring power consumption over extended periods, which is crucial for optimizing device efficiency and performance.

• Bug Identification

  It helps in identifying bugs in systems by accurately measuring voltage, current, and power, allowing for the recreation of problematic scenarios.

• Automation and Control

  Quarch's tools support automation, enabling continuous testing and monitoring, which is essential for large-scale operations.

Conclusion

Quarch's Power Analysis Module is a powerful tool for engineers and developers looking to analyze power consumption accurately in various applications, from data storage to automotive systems. Its advanced features and ease of use make it a valuable asset in the field of power analysis.

The Quarch Programmable Power Module (PPM) is a versatile tool used for testing and analyzing power supply performance. It supports various devices, including SSDs, HDDs, and PCIe/SAS/SATA devices, and allows for detailed measurements of voltage, current, and power consumption.

Key features include:

• Flexible Outputs

  Supports 12V and 5V (switchable to 3V3) outputs, ideal for different device types.

• Real-World Measurement

  Operates in a real-world environment, providing accurate measurements of power supplied from the host system to the device under test.

• Advanced Capabilities

  Allows for complex scenarios like power margining, ramping, and glitching, with programmable voltage output waveforms.

• High-Speed Recording

  Features a high-speed record function for capturing detailed data over extended periods.
